How to use Stack with Material Bottom Tab Navigation in React Native?

When “How to use Stack with Material Bottom Tab Navigation in React Native?” moves through design, development and browser testing, workplace fundraising events can clarify hand-offs and time spent on revisions while leaving code quality, accessibility and released behaviour as the real measures of success.

For API changes, browser support and current usage patterns, compare the snippet with the React Native project before adopting it in production.

Jun 02, 2022

Hi Guys,

In this tutorial, you will learn how to use stack with material bottom tab navigation in react native. I explained simply step by step how to implement stack with material bottom tab navigation in react native. we will help you to give example of stack with material bottom tab navigation example in react native. This tutorial will give you simple example of react native stack with material bottom tab navigation example.

In this example, there are 3 screens (Home, Cart, and Images) defined using the Tab.Screen component and 1 screen (Test) defined using the Stack.screen component. Similarly, you can define as many screens as you like.

Step 1: Download Project

In the first step run the following command to create a project.

expo init ExampleApp

Step 2: Installation and Setup

First, you need to install them in your project:

npm install @react-navigation/native @react-navigation/stack @react-navigation/material-bottom-tabs react-native-paper

You also need to install react-native-gesture-handler.

npm install react-native-gesture-handler

you can set drawer icon to install vector icons:

npm i react-native-vector-icons

you have use any bundled Icon:

import this:

import Icon from 'react-native-vector-icons/Ionicons';

Step 3: HomeScreen.js first of all you have create Screens folder inside your project.in this folder create HomeScreen.js file

In this step, You will open the HomeScreen.js file and put the code.

Screens/HomeScreen.js

import React from 'react';
import { StyleSheet, Text, View, Button } from 'react-native';
const HomeScreen = (props) => {
    const gotoTestStackScreen = () => {
        props.navigation.navigate('Test');
    };
    return (
        <View style={styles.container}>
            <View>
                <Text style={styles.text}>HomeScreen!</Text>
            </View>
            <Button title="Go to test test screen" onPress={gotoTestStackScreen} />
        </View>
    );
}
const styles = StyleSheet.create({
    container: {
        flex: 1,
        justifyContent: 'center',
        alignItems: 'center',
    },
    text: {
        fontSize: 20,
        marginBottom: 10,
    },
});
export default HomeScreen;

Step 4: CartScreen.js

Next,create CartScreen.js file inside Screens folder

In this step, You will open the CartScreen.js file and put the code.

Screens/CartScreen.js

import React from 'react';
import { StyleSheet, Text, View } from 'react-native';
const CartScreen = () => {
    return (
        <View style={styles.container}>
            <Text style={styles.text}>CartScreen</Text>
        </View>
    );
}
const styles = StyleSheet.create({
    container: {
        flex: 1,
        justifyContent: 'center',
        alignItems: 'center',
    },
    text: {
        fontSize: 20,
    },
});
export default CartScreen;

Step 5: ImageScreen.js

Next,create ImageScreen.js file inside Screens folder

In this step, You will open the ImageScreen.js file and put the code.

Screens/ImageScreen.js

import React from 'react';
import { StyleSheet, Text, View } from 'react-native';
const ImageScreen = () => {
    return (
        <View style={styles.container}>
            <Text style={styles.text}>ImageScreen</Text>
        </View>
    );
}
const styles = StyleSheet.create({
    container: {
        flex: 1,
        justifyContent: 'center',
        alignItems: 'center',
    },
    text: {
        fontSize: 20,
    },
});
export default ImageScreen;

Step 6: TestScreen.js

Next,create TestScreen.js file inside Screens folder

In this step, You will open the TestScreen.js file and put the code.

import React from 'react';
import { StyleSheet, Text, View } from 'react-native';
const TestScreen = () => {
    return (
        <View style={styles.container}>
            <Text style={styles.text}>TestScreen</Text>
        </View>
    );
}
const styles = StyleSheet.create({
    container: {
        flex: 1,
        justifyContent: 'center',
        alignItems: 'center',
    },
    text: {
        fontSize: 20,
    },
});
export default TestScreen;

Step 7: App.js

Now, you need to wrap the whole app in NavigationContainer. Usually, you'd do this in your entry file, such as App.js:

In this step, You will open the App.js file and put the code.

import * as React from 'react';
import { NavigationContainer } from '@react-navigation/native';
import { createStackNavigator } from '@react-navigation/stack';
import { createMaterialBottomTabNavigator } from '@react-navigation/material-bottom-tabs';
import Icon from 'react-native-vector-icons/Ionicons';
import HomeScreen from './Screens/HomeScreen';
import CartScreen from './Screens/CartScreen';
import ImageScreen from './Screens/ImageScreen';
import TestScreen from './Screens/TestScreen';
const Tab = createMaterialBottomTabNavigator();
const MyTabs = () => {
    return (
        <Tab.Navigator>
            <Tab.Screen
                name="Home"
                component={HomeScreen}
                options={{
                    tabBarIcon:({ color,focused }) => (
                        <Icon name='home' size={focused ? 25 : 20} color={color}  />
                    ),
                }}
            />
            <Tab.Screen
                name="Cart"
                component={CartScreen}
                options={{
                    tabBarIcon:({ focused, color }) => (
                        <Icon name='cart' size={focused ? 25 : 20}  color={color} />
                    ),
                }}
            />
            <Tab.Screen
                name="Images"
                component={ImageScreen}
                options={{
                    tabBarIcon:({ focused, color }) => (
                        <Icon name='images' size={focused ? 25 : 20}  color={color} />
                    ),
                }}
            />
        </Tab.Navigator>
    );
}
const Stack = createStackNavigator();
const App = () => {
    return (
        <NavigationContainer>
            <Stack.Navigator
                initialRouteName="Tabs"
                screenOptions={{
                    headerTitle:'Logo',


                }}
            >
                <Stack.Screen
                    name="Test"
                    component={TestScreen}
                    options={{
                        headerShown: true,
                        headerTitle:'Test',
                    }}
                />
                <Stack.Screen name="Tabs" component={MyTabs} />
            </Stack.Navigator>
        </NavigationContainer>
    );
}
export default App;

Run Project

In the last step run your project using the below command.

expo start

You can QR code scan in Expo Go Application on mobile.

Output :

It will help you...
